KMC Controls FlexStat Application Guide

FlexStat (General) 26 Application Guide, Rev L
Support
FlexStats come with a printed Installation Guide. The
latest support les for the FlexStat are always available
on the award-winning KMC Controls web site (www.
kmccontrols.com). You may need to log-in to the Part-
ners site (hps://partners.kmccontrols.com) to see all
available les.
The collection of FlexStat documents won a prestigous
publications award for technical marketing support from
the Chicago chapter of the Society for Technical Com-
munication in March 2010.
For operation, conguration, troubleshooting and other
information, see the FlexStat Opera-
tion Guide.
For specications, see the FlexStat
Data Sheet.
For additional instructions on program-
ming, see the Help system for BACstage
or TotalControl.
Important Notices
The KMC logo is a registered trademark and FlexStat, TotalControl, and
BACstage are trademarks of KMC Controls, Inc. All rights reserved. No
part of this publication may be reproduced, transmied, transcribed,
stored in a retrieval system, or translated into any language in any form
by any means without the wrien permission of KMC Controls, Inc.
The material in this document is for information purposes only. The
contents and the product it describes are subject to change without
notice. KMC Controls, Inc. makes no representations or warranties with
respect to this document. In no event shall KMC Controls, Inc. be liable
for any damages, direct or incidental, arising out of or related to the use
of this document.
Troubleshooting Motion Sensor Operation
• The initial rmware (R.1.0.0.0 and earlier) did not support this sen-
sor within the built-in selectable programs. Custom programming
was required. Upgrade to the latest rmware for built-in support.
• Aer an initial power-up or restart, the motion sensor requires about
30 seconds before it will begin responding to motion.
• The motion sensor initiates override only during “o” times in the
schedule. Check the schedule.
• Check that the motion sensor is enabled and detects motion. See
Enabling/Disabling the Sensor and Override Time on page 23.
• Using BACstage or TotalControl, check that BI6 (occ status) is not
congured as “Out of Service.”
• See Performance and Applications on page 22 about eective range,
false detections, and other detection issues.
• The FlexStat must be installed where there is a clear view of typical
occupancy movement (reliable range is out to about 33 feet). Remove
or move obstacles. Reinstall the FlexStat in a more optimal location if
necessary. See also Adding a Door Contact for Additional Control on
page 24.
• For extended range or views around obstacles, connect remote
motion sensors to an input. See Adding Remote Motion Sensors on
page 25.
• For the program in Customizing the Motion Sensor and Override on
page 23, Occupancy Override time in the System menu must not be set
to 0.
NOTE: This program will work with the built-in motion sensor
enabled or disabled. It will also work with FlexStat models that
have no built-in motion sensor.
NOTE: See important information about custom programming in
Custom Programming on page 8.
