KMC Controls FlexStat Application Guide

BAC-1xx63/1xxx63 Series (6 Relays and 3 Analog Outputs) Section 29 Application Guide L
HPU (Heat Pump Unit)—
1 or 2 Compressors w/ Aux. & Emergency Heat
BILL OF MATERIALS: HPU, DAMPER ACTUATORS
REFERENCE
MAX DAMPER
AREA IN FT
2
KMC PART # PART DESCRIPTION
OAD or RTD 6.25 MEP-5372
50 IN·LB FAIL-SAFE ACTUATOR, 2-10VDC,
19VA
OAD or RTD 15 MEP-7252
120 IN·LB FAIL-SAFE ACTUATOR, 0-10VDC,
25VA
OAD or RTD 22.5 MEP-7552
180 IN·LB FAIL-SAFE ACTUATOR, 0-10VDC,
25VA
OAD or RTD 40 MEP-7852
320 IN·LB FAIL-SAFE ACTUATOR, 0-10VDC,
40VA
NOTE: See the corresponding BAC-1xx63 or BAC-1xxx63
Installation Guide section for detailed drawings and input/
output connections as well as other important installation
information.
RTU (Roof Top Unit)—1 or 2 Heat and 1 or 2 Cool
NOTE: This was 2 Heat and 2 Cool in rmware R1.3.04 and earlier.
Multistage was added later.
BILL OF MATERIALS: HPU, 1/2 Compressors w/ Aux. & Emergency Heat
REFERENCE KMC PART # PART DESCRIPTION
FLEXSTAT
BAC-1xx63/
1xxx63
BACNET THERMOSTAT, 6 RELAY & 3 ANALOG OUTPUTS
DAT STE-1402 DUCT TEMPERATURE SENSOR
FST CSE-1102 AIR DIFFERENTIAL PRESSURE SWITCH, 0.05-12" WC
MAT STE-1416 12' DUCT AVERAGING TEMP SENSOR
OAT STE-1451 OUTSIDE TEMPERATURE SENSOR
* STE-6011 REMOTE TEMPERATURE SENSOR, TYPE II
* SAE-10xx REMOTE CO
2
SENSOR, SPACE OR DUCT
CHOOSE ONE OF THE FOLLOWING TRANSFORMERS:
TX2 XEE-6311-075 TRANSFORMER, 120/208/240/480:24 VAC, 75 VA
TX2 XEE-6311-100 TRANSFORMER, 120/240/277/480:24 VAC, 96 VA
*The remote temperature and CO
2
sensor options are not shown in the sample installation
diagrams, and they are available only on BAC-12xxxx/13xxxx/14xxxx models.
BILL OF MATERIALS: RTU, DAMPER ACTUATORS
REFERENCE
MAX DAMPER
AREA IN FT
2
KMC PART # PART DESCRIPTION
OAD or RTD 6.25 MEP-5372
50 IN·LB FAIL-SAFE ACTUATOR, 2-10VDC,
19VA
OAD or RTD 15 MEP-7252
120 IN·LB FAIL-SAFE ACTUATOR, 0-10VDC,
25VA
OAD or RTD 22.5 MEP-7552
180 IN·LB FAIL-SAFE ACTUATOR, 0-10VDC,
25VA
OAD or RTD 40 MEP-7852
320 IN·LB FAIL-SAFE ACTUATOR, 0-10VDC,
40VA
BILL OF MATERIALS: RTU, 1 or 2 Heat and 1 or 2 Cool
REFERENCE KMC PART # PART DESCRIPTION
FLEXSTAT
BAC-1xx63/
1xxx63
BACNET THERMOSTAT, 6 RELAY & 3 ANALOG OUTPUTS
DAT STE-1402 DUCT TEMPERATURE SENSOR
FST CSE-1102 AIR DIFFERENTIAL PRESSURE SWITCH, 0.05-12" WC
MAT STE-1416 12' DUCT AVERAGING TEMP SENSOR
OAT STE-1451 OUTSIDE TEMPERATURE SENSOR
* STE-6011 REMOTE TEMPERATURE SENSOR, TYPE II
* SAE-10xx REMOTE CO
2
SENSOR, SPACE OR DUCT
CHOOSE ONE OF THE FOLLOWING TRANSFORMERS:
TX2 XEE-6311-075 TRANSFORMER, 120/208/240/480:24 VAC, 75 VA
TX2 XEE-6311-100 TRANSFORMER, 120/240/277/480:24 VAC, 96 VA
*The remote temperature and CO
2
sensor options are not shown in the sample installation
diagrams, and they are available only on BAC-12xxxx/13xxxx/14xxxx models.
NOTE: On BAC-12xxxx/13xxxx/14xxxx models, when IN7 is
congured for a remote space temperature sensor, space
temperature can be congured for onboard, remote, averaging
of the two, the lowest reading, or the highest reading. When
DCV is enabled, IN9 is assumed to be connected to an external
SAE-10xx CO
2
sensor. See the FlexStat Operation Guide for
more details.
