BAC-1xx30 Series (3 Relays and 0 Analog Outputs) Section 56 Application Guide L
Bills of Materials (BAC-1xx30)
AHU (Air Handling Unit)—1 Heat and 1 Cool
CAUTION
Relays are for Class-2 voltages (24 VAC) only. Do not connect line
voltage to the relays!
NOTE: See the BAC-1xx30 Installation Guide section for detailed
drawings and input/output connections as well as other
important installation information.
NOTE: Humidity and motion/occupancy sensor options are dependent
on the FlexStat model. In BAC-10130/11130, dehumidication
or economizer options can be selected but not both.
NOTE: See also Sequence of Operation (BAC-1xx30) on page 57.
BILL OF MATERIALS: AHU, 1 Heat and 1 Cool
REFERENCE KMC PART # PART DESCRIPTION
FLEXSTAT BAC-1xx30 BACNET THERMOSTAT, 3 RELAYS
DAT STE-1402 DUCT TEMPERATURE SENSOR
FST CSE-1102 AIR DIFFERENTIAL PRESSURE SWITCH, 0.05-12" WC
MAT STE-1416 12' DUCT AVERAGING TEMP SENSOR
OAT STE-1451 OUTSIDE TEMPERATURE SENSOR
TX XEE-6311-075 TRANSFORMER, 120/240/277/480:24 VAC, 75 VA
BILL OF MATERIALS: Cooling Unit, 1 Cool
REFERENCE KMC PART # PART DESCRIPTION
FLEXSTAT BAC-1xx30 BACNET THERMOSTAT, 3 RELAYS
DAT STE-1402 DUCT TEMPERATURE SENSOR
FST CSE-1102 AIR DIFFERENTIAL PRESSURE SWITCH, 0.05-12" WC
TX XEE-6311-075 TRANSFORMER, 120/240/277/480:24 VAC, 75 VA
BILL OF MATERIALS: Heating Unit, 1 Heat
REFERENCE KMC PART # PART DESCRIPTION
FLEXSTAT BAC-1xx30 BACNET THERMOSTAT, 3 RELAYS
DAT STE-1402 DUCT TEMPERATURE SENSOR
FST CSE-1102 AIR DIFFERENTIAL PRESSURE SWITCH, 0.05-12" WC
TX XEE-6311-075 TRANSFORMER, 120/240/277/480:24 VAC, 75 VA
Heating Unit—1 Heat
Cooling Unit—1 Cool
HPU (Heat Pump Unit)—1 Compressor
BILL OF MATERIALS: HPU, 1 Compressor
REFERENCE KMC PART # PART DESCRIPTION
FLEXSTAT BAC-1xx30 BACNET THERMOSTAT, 3 RELAYS
DAT STE-1402 DUCT TEMPERATURE SENSOR
FST CSE-1102 AIR DIFFERENTIAL PRESSURE SWITCH, 0.05-12" WC
TX XEE-6311-075 TRANSFORMER, 120/240/277/480:24 VAC, 75 VA
