KMC Controls FlexStat User Manual

FlexStat 10 Operation Guide, Rev. R
Setback (OAT) Lockout Setup
SETBACK LOCKOUT
OAT LOCKOUT:
LOCKOUT TEMP: 30° F
ENABLE
Setback OAT lockout is disabled by default. When
enabled, AI4 is congured for OAT and the Lockout
Temp selection appears in the menu. This may be
useful when a system, such as an HPU, may have
diculty recovering from the unoccupied setpoint to
the occupied setpoint during very cold weather.
NOTE: When enabled, the default value is 30° F
(–1° C) for HPU and 10° F (–12° C) for all
other applications. The value is adjustable
between –50 and 120° F (–45.5 and 49° C).
Staging Setup
STAGING
STG DELAY (MINS):
3
After the rst stage starts in multistage heating or
cooling, the default delay time before the second
stage can start is 3 minutes.
Valve Setup
VALVE SETUP
CLG (0–100%):
HTG (0–100%): 0–10V
0–10V
Proportional valves have a 0–10 VDC default for
0–100% open. Change as needed (e.g., 10–2 VDC).
(Advanced) CB (Control Basic) Programs
CB PROGRAMS
PROG1:
PROG2: RUNNING
PROG3: RUNNING
PROG4: RUNNING
PROG5: RUNNING
PROG6: HALTED
PROG7: IDLE
RUNNING
PROGRAM #1
SETPOINTS & MODES
AUTO-RUN: TRUE
CHANGE: READY
STATE: RUNNING
HALT REASON: NORMAL
HALT DESC:
OUT OF SERVICE: FALSE
To halt or load/run the built-in (1–5) and custom
(6–10) Control Basic programs, navigate to the de-
sired line and selection.
If custom Control Basic programs are installed and a
restoretofactoryseingsisperformed,allfactory
programsarerestartedbutallcustomControlBasic
programsarehalted.Change the state of each pro-
gram by loading/running the program from the CB
Programs menu (or BACstage or TotalControl).
If custom Control Basic programs are installed and
settoautorun, whenever the rmwareisupdated,
ALL(factoryandcustom)programsarehalted.If
custom Control Basic programs are installed but
NOTsettoautorun,whenever the rmware is up-
dated, factory programs are restarted but any (manu-
al) running custom programs are halted at restart.
Change the state of each custom program by using
the Update Manager or loading/running each pro-
gram from the CB Programs menu (or BACstage or
TotalControl).
UPDATE MANAGER
PROGRAM CONFIG ERROR
ENABLE FACTORY:
ENABLE CUSTOM: NO
EDIT CB PROGRAMS
DONE
NO
In the About menu, ASV will show CUSTOM if any
built-in Control Basic program (1–5) is not running
or has auto-run disabled. See About the FlexStat on
page 6.
NOTE: Customizedprogramsaretheresponsibility
oftheuser. KMC Controls does not provide
support for such programs.
