KMT Streamline SL-IV - Hydraulic Intensifier Assembly Parts

SECTION 12 PARTS LISTS
p. 12-6
05139159
Figure 12-2 HYDRAULIC INTENSIFIER ASSEMBLY 80079999
ITEM No. QTY. PART No. DESCRIPTION
1 2 05144647 Body, Cylinder, HP, 1.13-in. ID
2 2 05119151 Plunger, Ceramic
3 2 80072349 Head Assembly, Sealing
4 2 05034772 Head, Cylinder
5 2 05149703 Seal Assembly
6 2 05144696 Seal Spacer
7 2 80073646 Nut, Retaining, Sealing Head
8 2 05130091 Seal Assembly, Plunger, Cartridge, Hydraulic
9 2 05007786 Flange, Retaining, Bushing
11 2 05144712 Liner, HP Cylinder
12 4 10074920 O-ring
13 12 80070352 Jackbolt
14 2 05034798 Ring, Retaining
15 1 05034764 Cylinder, Hydraulic
16 2 10075000 O-ring
17 2 05034855 Ring, Backup
18 16 05141106 Cap Screw, Socket Head, M14x60
19 2 05127584 Switch, Proximity, 20-250 VAC/VDC
20 4 10183572 Cap Screw, Socket Head, M6x1x22mm
21 1 05132253 Piston Assembly, Hydraulic
27 2 10074409 O-ring
28 2 05144183 Spacer, Proximity Switch
30 * 10148674 Special Tool, HP Seal Removal (Not Shown)
31 * 05066139 Special Tool, Wrench, HP Cylinder (Not Shown)
32 * 05004924 Special Tool, Plunger Removal
