SECTION 12 PARTS LISTS

p. 12-8

05139159

Figure 12-3 SEALING HEAD ASSEMBLY 80072349

ITEM No. QTY PART No. DESCRIPTION

1 1 49834039 Body, Sealing Head

2 1 05144662 Poppet, Inlet, Cutting Water

3 1 05116777 Gland, HP, Sealing Head

4 1 05112768 Seat, HP, Sealing Head

5 1 05116561 Poppet, Valve, HP Check

1 05144670 Retainer, Poppet

7 1 05147863 Spring, Compression

8 1 49884562 Spring, Compression

9 1 05116751 Pin, Guide
