SECTION 12 PARTS LISTS

p. 12-10

05139159

Figure 12-4 HYDRAULIC PISTON ASSEMBLY 05132253

ITEM No. QTY PART No. DESCRIPTION

1 1 05132261 Body, Hydraulic Piston

12 05074380 Pin, Clevis

3 2 05049887 Screw, Set, Socket, with Through Hole

4 2 10148757 Valve, Check, Cartridge, with O-ring

5 -- 49877509 Adhesive, Thread Locker

6 2 05088364 Ring, Snap, Flat Wire

7 2 05049994 Ring, Backup

8 2 05087713 O-ring

9 1 05117965 Seal Assembly, Hydraulic Piston

10 2 05117940 Bearing, Hydraulic Piston
