SECTION 12 PARTS LISTS

p. 12-12

05139159

Figure 12-5 HYDRAULIC CARTRIDGE SEAL ASSEMBLY 05130091

ITEM No. QTY PART No. DESCRIPTION

1 05130109 Body, Seal, Cartridge

2 2 05015060 Seal, U-Cup, with O-ring

3 1 10193522 O-ring

4 1 05050760 Ring, Backup

5 1 05129481 O-ring

6 1 05013024 O-ring

7 1 05129515 Back-up Ring

8 1 05027255 Seal, U-Cup

Ref 1 0 05009048 Tool, Seal Installation
