KMT Streamline SL-IV User Manual

SECTION 12 PARTS LISTS
FIGURE 12-6 HIGH PRESSURE WATER ASSEMBLY, 80080153
ITEM No QTY PART No. DESCRIPTION
1 1 05127519 Tube, Bent, .38-in. HP, 60 ksi, Stainless
2 1 05127501 Tube, Bent, .38-in. HP, 60 ksi, Stainless
3 2 10078590 Tee, .38-in. HP Tube, 60 ksi, Stainless
4 2 10079531 Reducer Coupling, .38 x .56, 60 ksi, Stainless
5 1 05127972 Tube, Bent, .38-in. HP, 60 ksi, Stainless
6 2 10078129 Gland, .38-in. HP Tube, 60 ksi, Stainless
7 2 10078715 Collar, .38-in. HP Tube, 60 ksi, Stainless
8 1 80079999 Intensifier Assembly
9 1 05127659 HP Attenuator
10 10 10083897 Ferrule, .25, Brass
11 1 05129721 Manifold Assembly
12 100” 10186153 Conduit, Extra Flexible, .38-in. ID
13 2 05131107 Manifold Gasket
14 4 05092903 Attenuator Bracket Spacer
15 4 95413696 Lock Washer, .50
16 4 95383790 Socket Head Screw, 1/2-13 x 1.00
17 1 05129374 Tube, Bent, .38-in. HP, 60 ksi, Stainless
18 1 05129390 Tube-HP, .25 x 35.00
19 1 05069703 Pneumatic Valve Assembly
20 1 10094704 Tube-HP, .25 x 3.00
21 1 10078160 Bulkhead Coupling, .38
22 1 05129366 Tube, Bent, .38-in. HP, 60 ksi, Stainless
23 2 95896379 Socket Head Screw, 1/4-28 x 3/4
24 2 95838314 Lock Washer, .25
25 2 95391322 Washer, .25
26 8 05050323 Socket Head Screw, M10 x 1.50 x 90mm
27 8 05061486 Lock Washer, M10
28 2 10074409 O-ring
p. 12-14
05139159
