SECTION 12 PARTS LISTS

Figure 12-7 HYDRAULIC MANIFOLD ASSEMBLY, 05129721

ITEM No. QTY PART No. DESCRIPTION

1 1 05129549 Block, Manifold, Hyd

2 1 10114908 Valve, Pressure Unloading, Startup

3 1 05071717 Valve, Relief, Hyd, 234 bar (3,400 psi)

4 7 05104559 Plug, -6 SAE O-ring Port

5 1 10192813 Plug, -4 SAE O-ring Port

6 1 05057567 Adapter, -12 SAE O-ring x –8 JIC

7 1 10144749 Adapter, -4 JIC x –4 SAE O-ring, Straight

8 1 10087880 Adapter, -8 SAE O-ring x –8 JIC

9 4 10110567 Cap Screw, Socket Head

10 4 95367728 Washer

11 1 05129069 Valve, Directional Control, Air-Operated

12 2 10078095 Coupling, Male, .25 .125

p. 12-16

05139159
