KMT Streamline SL-IV User Manual

SECTION 12 PARTS LISTS
Figure 12-8 BULKHEAD PIPING ASSEMBLY, 80080179
ITEM No QTY
PART No. DESCRIPTION
1 1 10091866 Valve, Modulating
2 4 10078194 Bulkhead Adapter, ½-1-1/2 NPT
3 - 10127348 Hose, Push-On, .50-in. ID
4 1 10073823 Tee, Male Run, ½-NPT, Brass
5 1 05126289 Filter Assembly, LP Water
6 1 49834328 Adapter, .25 OD Tube x ½ - NPT
7 1 10077055 Adapter, Bulkhead, 4-15
8 1 10189900 Tee, Male Run, ¼ x 1/8 NPT,
9 - 10079903 Tube, Polyethylene, .25-in. OD
10 1 10145829 Nipple, Close, ½-NPT, Brass
11 2 49834302 Adapter, Tube/Pipe, .50
12 2 05128947 Adapter, 1/4 NPT x .-8 JIC,
13 5 10079713 Barb, .50, NPT
14 3 10173805 Barb, Hose, 0.50 x –8JIC
15 5 05113964 Grommet
16 1 10147460 Elbow, ½-NPT x –8 JIC, 90 degree
17 1 10100477 Bushing, ¼ x1/8 NPT, Brass
18 1 05128715 Valve, Solenoid, 24vdc
19 1 05112271 Muffler, Pneumatic, 1/8-NPT
20 2 05143508 Screw, Machine, #4-40 x 1-1/2
21 2 10118214 Lockwasher #5-40
22 2 10078095 Coupling, Poly, ¼ x 1/8 NPT
23 1 10077030 Elbow, 90-deg, M, .25 x .13
24 2 95146403 Hex Nut, #4-40
25 1 49834310 Adapter, Tube/Pipe, .50
26 3 49831480 Grommet
p. 12-18
05139159
