SECTION 12 PARTS LISTS
Figure 12-10 MOTOR / PUMP ASSEMBLY, 05125919
ITEM No. QTY PART No. ITEM DESCRIPTION
1 2 05144027 Mount, Vibration Isolation, Motor Base
2 4 10170686 Washer, Lock, ½-in. ID, Stainless
3 4 10066199 Cap Screw, Hex Head, 1/2-13 x ¾, SST
4 1 05125927 Motor, Electric, 15hp, SAE–C Face, 200/400/230/460/3ph/50-60 Hz
5 2 95738514 Cap Screw, Hex Head, 1/2-13 x 1
6 -- 10184802 Grease, Anti-Seize, “Optimal”
7 1 05125935 Piston Pump, Hyd, 28cc/Rev, Thru Shaft, 3000 psi
8 2 10069714 Washer, Flat, .38-in. ID
9 2 05037593 Cap Screw, Socket Head, M10 x 1.50 x 25mm, SST
10 1 05126008 Pump, Gear, Hyd, 22cc/Rev
11 1 05126339 Elbow, Hyd, -20/4-Bolt Flange x –20 Hose Barb
13 1 05045497 Pressure Gage, Hyd, 0-5,000 psi, -4 SAE O-ring
14 2 05089867 Adapter, Hyd, -8 JIC x –12 SAE O-ring, Straight
16 1 05127402 Adapter, Hyd, -8 JIC x –8 SAE O-ring, 90 Degree
17 1 49881774 Adapter, Hyd, -12 JIC x –12 SAE O-ring, 45 Degree
18 1 10119337 Split Flange Kit, Hyd, -20-4 Bolt Flange w/O-ring, Cap Screws
20 4 05041058 Cap Screw, Socket Head, 3/8-16 x 2.25”
21 4 95688743 Washer, Lock, High Collar, 0.38 ID
22 1 10074409 O-ring
23 1 05130935 Check Valve Cartridge
24 1 05130885 Check Valve Hydraulic Manifold
p. 12-22
05139159
