SECTION 12 PARTS LISTS
Figure 12-11 HYDRAULIC RESERVOIR ASSEMBLY, 05126230
ITEM No QTY PART No. DESCRIPTION
2 1 05050026 Switch, Temperature / Level, Hyd, Cartridge- Type, 149 deg F
3 1 05092739 Breather, Air, 40 Micron, 3/8” NPT
4 1 10168862 Gage, Dual Scale, Level/Temperature, Oil
5 1 05049697 Housing, Filter, Hyd Oil, w/Gage, 50psi Bypass Valve, -12 SAE O-ring
6 1 05049689 Element, Filter, Hyd Oil, Spin-on Type, 6 – Micron Absolute
7 1 05130968 Tee-Male Branch, Pipe/JIC, 12-12
8 1 05069976 Cap, ¾ NPT Hex, Steel
9 1 05047451 Adapter-JIC/O-ring, 90 degree, 12-12
10 1 05129424 Oil Cooler, Hyd
11 1 10091858 Bulb Well, ¾” NPT
12 1 05057559 Adapter, -12 SAE O-ring x ¾” NPT, Straight, Steel
13 3 10099901 Elbow-1/4” NPT x –4 JIC, 90 Degree, Steel
14 1 10080901 Ball Valve, ½” NPT, Bronze
15 1 95033619 Plug-Square Head, ½” NPT, Steel
16 1 05079371 Adapter, 12 JIC x –12 BSPP, Straight, Steel
17 1 10057719 Adapter, ¾” NPT x -8 JIC, 90 Degree, Steel
18 4 95416319 Hex Head Screw, 3/8-16 x 1
19 4 10069714 Washer, 0.38
20 4 95750394 Lock Washer, 0.38
21 1 49879513 Elbow-Pipe/JIC, 90 degree, 12-12
22 1 05060777 Adapter, JIC,45 degree, Male/Female, 12-12
Ref 1 0 05126941 Reservoir Weldment
Ref 2 0 05127949 Reservoir Lid
Ref 3 0 05127071 Reservoir Support Weldment
Ref 4 0 05128160 Gasket, Cover, Reservoir
p. 12-24
