KMT Streamline SL-IV User Manual

SECTION 1
INTRODUCTION
July 2003
1-9
05130661
Rear of Waterjet Pump
A HP Water "OUT"
B Plant Air "IN"
C Cooling Water "IN"
D Cooling Water "OUT
E " Cutting Water "IN"
F Drain
The following figure shows other safety labels or icons used on the SL-IV waterjet
pump. Trapped HP water or oil warning warns against the hazard of trapped HP
water or hydraulic pressure after the pump has been shut off. Typically all
pressure can be safely bled off if the operator will leave the HP cutting water valve
open for a few seconds after shutting off the pump.
Electrical shock hazard warns of electrical shock hazard when in the vicinity of the
electrical enclosure or motor junction box. Hot surface warning warns of hot
surfaces on the HP water and hydraulic components while the pump is in normal
operation.

KMT Streamline SL-IV Specifications

General

Brand	KMT
Model	Streamline SL-IV
Category	Water Pump
Language	English
