INSTALLATION INSTRUCTIONS Installation
10MAR06
II4825-1
Page
24 of 72
5 Connect:
CABLE Description From: To:
A SERIAL IN MONITOR COMPUTER COM 1 CONNECTOR
B VGA IN MONITOR COMPUTER MONITOR CONNECTOR
C MONITOR POWER MONITOR MONITOR POWER/SOUND CABLE
D Y CABLE BAR CODE
READER
KEYBOARD EXTENSION CABLE
E BAR CODE READER Y CABLE KEYBOARD CABLE
F KEYBOARD
EXTENSION CABLE
Y CABLE COMPUTER KEYBOARD CONNECTOR
G MOUSE MOUSE MOUSE EXTENSION CABLE
H MOUSE EXTENSION MOUSE CABLE COMPUTER MOUSE CONNECTOR
I RS-232 optional MODEM COMPUTER COM 2 CONNECTOR 2.4
GHZ COM 4 on 3.0 GHZ
J NETWORK CUSTOMER
NETWORK
COMPUTER NETWORK CARD
CONNECTOR
K NETWORK MCPU BOARD
(A2)
COMPUTER ONBOARD NETWORK
CONNECTOR
L KEYBOARD KEYBOARD KEYBOARD CONNECTION CABLE
To Next Page
