Diagnostics
SM1399-1 – 19JUN06 21
Communication
General Functions
Description Recommended Action
The CAMERA does not download images from the USB
PORT.
1. Connect the CAMERA to the computer to check for
communication.
2. Check for damage on:
• USB CONNECTOR to the PINS on the J3 on the
MCU BOARD
• BOARD-TO-BOARD CONNECTOR J1 on the
MCU BOARD/LENS AY to J3 on the POWER
BOARD
3. Install a new MCU BOARD/LENS AY.
Description Recommended Action
One or more do not operate correctly:
•“menu” BUTTON
• FLASH BUTTON
•“share” BUTTON
•“delete” BUTTON
•“review” BUTTON
• 4-WAY BUTTON
•“OK” BUTTON
1. Check for damage to:
• BUTTONS
• inside the BACK COVER AY
2. Install a new:
• BACK COVER AY
• MCU BOARD/LENS AY
The SHUTTER BUTTON does not operate correctly. 1. Check the connection of the SHUTTER BOARD to
the MCU BOARD/LENS AY.
2. Install a new:
• SHUTTER BOARD
• MCU BOARD/LENS AY
The SELF-TIMER LED does not operate correctly. Check the connection of the red and black wires from
the SELF-TIMER LED to the MCU BOARD/LENS AY.
