SERVICE MANUAL
20 19JUN06 – SM1399-1
Power
Image Quality
Description Recommended Action
The CAMERA does not energize. 1. Check:
power source for the CAMERA
FUSE F1 and F2 on the POWER BOARD. If
open, install a new FUSE.
BOARD-TO-BOARD CONNECTOR JP1 on the
MCU BOARD/LENS AY to J3 on the POWER
BOARD
2. Diagnose the MODULE that has the malfunction.
Disconnect all MODULES from the MODE DIAL
BOARD.
Connect the MODULES one at a time, until the
FUSE opens.
3. Install a new:
MODE DIAL BOARD
POWER BOARD
MCU BOARD/LENS AY
The CAMERA with no BATTERY does not operate on
the CAMERA DOCK.
1. Check the DOCK CONNECTOR on the CAMERA.
2. Install a new MCU BOARD/LENS AY.
Description Recommended Action
The images are black. 1. Check:
BOARD-TO-BOARD CONNECTOR J1 on the
MCU BOARD/LENS AY to J3 on the POWER
BOARD
FPC
any sound from the SHUTTER
2. Install a new MCU BOARD/LENS AY.
The image is not in focus.
The color of the image is not correct.
The images are too light.
The images are too dark.
The images have pixels that are continually
energized.
The captured image is other than the image
displayed on the VIEWFINDER AY.
Install a new MCU BOARD/LENS AY.
