Diagnostics
SM1399-1 – 19JUN06 19
MEMORY CARD
Smoke emits from the CAMERA when the STROBE is
actuated.
Check:
• connection of the red and black wires between the
STROBE AY and the POWER FRAME AY
• STROBE COVER or STROBE REFLECTOR AY
has no debris
The LAMP for the STROBE is dark. Do a replacement of the CAMERA.
Description Recommended Action
The CAMERA does not recognize the MEMORY CARD. 1. Use a new MEMORY CARD.
2. Check:
•“IMAGE STORAGE” option is set to “AUTO”
• SOCKET of the MEMORY CARD on the MCU
BOARD/LENS AY has no damage
3. Do “
Upgrading the Firmware Using the Internal
Memory” on Page 75.
Images are not stored on the MEMORY CARD. 1. Use a new MEMORY CARD.
2. Check:
• position of the WRITE PROTECT SWITCH on
the SD CARD
•“IMAGE STORAGE” option is set to “AUTO”
• SOCKET of the MEMORY CARD on the MCU
BOARD/LENS AY has no damage
3. Format the MEMORY CARD and capture an image
again.
4. Do “
Upgrading the Firmware Using the Internal
Memory” on Page 75.
Description Recommended Action
