SERVICE MANUAL
24 19JUN06 – SM1399-1
Checking the Power On “Self Test”
[1] Do Preparing the “C643_C603 Self_Test” MEMORY CARD on Page 70.
[2] Insert the “C643_C603 Self_Test” MEMORY CARD in the CAMERA:
[3] Do either:
• Install the CAMERA on the CAMERA DOCK.
• Insert a BATTERY that has a full charge into the CAMERA.
[4] Energize the CAMERA to execute the test.
[5] If the MONITOR LCD displays “Date and time have been reset”, select “CANCEL”.
[6] For each test displaying on the MONITOR LCD, do:
[7] When the test is completed, de-energize the CAMERA.
[8] Remove the MEMORY CARD.
Test Check:
“F/W: n.nnnn” version of the firmware
“MCU: n.nnnn” version of the MCU
“RGB Level Checking...” quality of the 6 colors
“Gray Level Checking...” quality of the 6 gray areas
“LEDs On/Off testing”•green LED on the front of the CAMERA illuminates
• red and green LEDs on the back of the CAMERA illuminate
“LCD On/Off testing” MONITOR LCD blinks
“Strobe testing” STROBE energizes once
“SDRAM testing”•“SDRAM OK”
•“IDRAM OK”
•“SD Card OK”
•“NAND Flash OK”
“IDRAM testing”
“SD card testing”
“NAND flash testing”
“Temperature checking...” message “OK”
“LCD Bad pixel testing” MONITOR LCD for:
• dark pixels in the white screen
• white pixels in the dark screen
To Next Page
