CVS-841/851 Chapter 7
Functional Registration
93132682-00 7-13
Continuous pressing of the
up arrow key increases the
gain with the gain index
number increased in the
window.
The same operation applies
to the down arrow key for
decreasing the gain.
The gain index number
varies from 0.0 to 10.0 with
0.1 increment.
The High Frequency 2 gain control can be
made with up and down keys.
1
1
5
5
.
.
2
2
H(1)
IMAGE SPEED １／１
14:22:56
SHIFT
００００
H(2)
L
1
1
0
0
0
0
5
5
1
1
5
5
2
2
0
0
H(2) GAIN
2.6
Up arrow key
The current setting is being set
to Shift mode. Press the SHIFT
key to turn this mode off.
Down arrow key
