CVS-841/851 Chapter 4
Installation
Figure 4.2 Service space required for CVS-841
Unit in mm (inch)
Fixing screws
(M5 screw, 5 pcs)
Display Unit
Mounting bracket
Figure 4.3 Fitting detail of CVS-851
Washer
Knurled fixing bolt
Unit in mm (inch)
65
2 9/16
147
5 25/32
147
5 25/32
65
2 9/16
[CVS-851]
