Kohler CV11-16 User Manual

8.14
Section 8
Electrical System and Components
CV11-15, CV460-465, CV490-495 Electric Start Engines 15 amp Battery Charging System
Figure 8-12. CV11-15, CV460-465, CV490-495 Electric Start Engines/15 amp Regulated Battery Charging
System.
Figure 8-13. CV16 Electric Start Engines/15 amp Regulated Battery Charging System.
Ground-to-Kill Lead (White)
(Violet)
(Blue)
(Red)
S
B
R
A
M
GND
Key Switch
Optional Oil
Sentry™
Switch
(Indicator
Light)
Optional Oil
Sentry™
Switch
(Shutdown)
Battery
_
+
Solenoid Starter
Fuel
Solenoid
Auto
Choke
Diodes
Optional
Fuse
Optional
Ammeter
B+
Rectifier
Regulator
AC
AC
Ignition
Module
Spark
Plug
Flywheel
Stator
CV16 Electric Start Engines 15 amp Battery Charging System
Ground-to-Kill Lead
A
M
R
S
Spark
Advance
Module
GND
B
Key Switch
White
Red
Black
Engine
Connector
Optional Oil Sentry
Indicator Light
Optional
Fuse
Battery
AC
AC
B+
Flywheel
Yellow
Black
Brown
Ignition
Module
Spark
Plug
Rectifier
Regulator
Fuel
Solenoid
Starter
Solenoid
Optional
Oil
Sentry™
Switch
(Indicator)
Optional
Oil Sentry™
Switch
(Shutdown)
Bendix
Starter
Red
Stator
