8.15
Section 8
Electrical System and Components
8
Figure 8-14. 15 amp Stator and Rectifier-Regulator.
Figure 8-15. Proper Connection to Test 15 amp Charging System.
DC Volt Meter
(-)
Battery
Ammeter
Flywheel Stator
Rectifier-Regulator
AC
B+
AC
Rectifier-Regulator
AC
B+
AC
15 Amp Stator
AC Leads
