TP-6714 4/10126 Appendix
View Exerciser Setup
D Exercise Event Number
D Enabled/Disabled
D Exercise Run Time
D Start Date
D Start Time
D Weekly/Biweekly
D Loaded/Unloaded
View System Setup
D Open/Programmed/Closed Transition
D Source Type: Util/Gen, Gen/Gen, Util/Util or Util/Gen/Gen
D Service Entrance: Yes/No
D In--Phase Monitor Enabled/Disabled
D Commit/No Commit to Transfer
D # I/O Modules Installed
D Rated Current
D 3 Src Engine Start Mode Mode1/Mode2
D Remote Test Loading Loaded/Unloaded
D Peak Shave Delay Enabled/Disabled
View Source Setup
D ABC/BAC Rotation (3-phase only)
D System Voltage, Normal/Emergency
D Frequency (Hz), Source N and E
D Normal Under Voltage PU% and DO%
d Normal Over Voltage PU% and DO%
d Debounce Time, Seconds
D Normal Under Frequency PU% and DO%
d Debounce Time
D Normal Voltage Unbalance Enable/Disable
d Normal Voltage Unbalance PU% and DO%
D Emergency Under Voltage PU% and DO%
d Emergency Over Voltage PU% and DO%
d Debounce Time
D Emergency Under Frequency PU% and DO%
d Emergency Over Frequency PU% and DO%
d Debounce Time
D Emergency Voltage Unbalance Enable/Disable
d Emergency Voltage Unbalance PU% and DO%
D In-Phase Monitor
d Enabled/Disabled
d Angle, degrees
D In-Phase Transfer Fail
d Enabled/Disabled
d Time Delay min:sec
View Source Setup, Continued
D Synchronization (for closed-transition)
d Voltage Differential
d Frequency Differential
d Angle differential
D Fail toSync
d Enabled/Disabled
d Time Delay min:sec
View Time Delays, Source S1 and Source S2
D Engine Start (gen set only)
D Engine Cooldown
D Xfr Preferred>Standby (Standby>Preferred)
D Xfr Off > Standby (Off >Preferred)
(programmed--transition only)
D Fail to Acquire Preferred (Standby)
D Load Control
d Mode: None/Time/Current
d Loads to Control (1--9)
D Time-Based Control
d Load Disconnect N>E (E>N) Time Delay min:sec
d Load Add E>N (N>E) Time Delay min:sec
D Current-Based Control
d Load Disc N>E (E>N) time delay min:sec
d Load control Source1 (Source2) Enabled/Disabled
d Load Add Source1 (Source2) Time Delay min:sec
d Load Add Source1 (Source2) Priority
d Load Remove Source1 (Source2) Time Delay min:sec
d Load RemoveSource1 (Source2) Priority
d Amps Level Remove Source1 (Source2)
d Amps Level Add Source1 (Source2)
View Inputs/Outputs
D Main Board I/O
d Input Function Descriptions (2)
d Output Function Descriptions (2)
D Auxiliary Inputs/ Outputs
d Aux I/O Module
d Module Type and Address
d Module Status
d Input Function Descriptions
d Output Function Descriptions
View Common Alarms
D Alarm Group (1 and 2)
D Alarm Description
D Audible (Yes or No)
D Common (Yes or No)
