Kohler MPAC 1500

TP-6714 4/1048 Section 4 View Screens
4.9 View Source Setup
View
Source Setup
BY "Main
View Source Setup
ABC Rotation
BY Back
View Source Setup
Norm 120V Emer 120V
60 Hz 60 Hz
BY Back
View Source Setup
Normal Under Voltage
PU 90% DO 90%
BY"Back
View Source Setup
Normal Under Freq
PU 90% DO 99%
BY"Back
View Source Setup
Norm Volt Unbalance
Enable
BY"Back
View Source Setup
Emer Under Voltage
PU 90% DO 90%
BY"Back
View Source Setup
Normal Over Voltage
PU 95% DO 115%
" Back
View Source Setup
Emer Under Freq
PU 90% DO 99%
BY"Back
View Source Setup
Emer Volt Unbalance
Enable
BY"Back
View Source Setup
Debounce 0.5S
Back
View Source Setup
Normal Over Freq
PU 110% DO 101%
" Back
View Source Setup
Debounce 3.0S
Back
View Source Setup
Normal Volt Unbalance
PU 10% DO 20%
Back
View Source Setup
Emer Over Voltage
PU 95% DO 115%
" Back
View Source Setup
Debounce 0.5S
Back
View Source Setup
Emer Over Freq
PU 110% DO 101%
" Back
View Source Setup
Debounce 3.0S
Back
View Source Setup
Emer Volt Unbalance
PU 10% DO 20%
Back
Continued on next page
3-phase only
3-phase only
