TP-6714 4/10 59Section 5 Setup
5.5 Setup Screens
From the main operation window, press the Set button to
enter the setup screens.
The setup password is required. The default password
is 0000. (The password can be disabled; see
Section 3.4.2.)
After entering the system password, use the black arrow
keys to step through the setup screens as shown in
Figure 5-5.
Timeout. After 10 minutes of no activity (no buttons
pressed) the controller exits the setup mode and returns
to the main screen.
System Ready
LD Exer ##/## @ ##:##
Norm ###V Emer ###V
B View Set Test
Incorrect Password
Enter Password
Time to Enter #:##
>?
???<
OK
Set Time/Date
BY "Main
Set Exerciser
BY "Main
Set S2 Time Delays
BY "Main
Set Passwords
BY "Main
Set Communications
BY "Main
Set Inputs/Outputs
BY "Main
Set Sources
BY "Main
Set System
BY "Main
Set Common Alarms
BY "Main
Password Disabled
OK
Calibration
<
Reset Data
BY "Main
BY "Main
Set S1 Time Delays
BY "Main
Set Prime Power Run
BY "Main
Appears if the password disable DIP
switch is set. Press OK to proceed.
Press the Set button in the main screen to enter the Setup screens.
The setup password is required.
Press the down arrow
B button to step to the next screen.
Press the right arrow
" button to enter the detailed setup screen.
Figure 5-5 Main Setup Screen
