Kohler MPAC 1500

TP-6714 4/10 55Section 4 View Screens
4.14 View Communications Setup
View
Communications Setup
BY "Main
View Comm Setup
MODBUS Server TCP
Enabled/Disabled
BY Back
View Comm Setup
MODBUS Server Port #
Enabled/Disabled
BY Back
View Comm Setup
MODBUS Addr Port #
###
BY Back
View Comm Setup
Baud Rate Port #
#####
BY Back
View Comm Setup
MODBUS TCP Unit ID
######
BY Back
View Comm Setup
IP Address
###.###.###.###
BY Back
View Comm Setup
Subnet Mask
###.###.###.###
BY Back
View Comm Setup
MAC Address
##-##-##-##-##-##
BY Back
Baud Rates:
9600
19200
57600
4.15 View Control Parameters
BY "Main
View
Control Parameters
BY Back
Control Parameters
Code Version:
BY Back
Control Parameters
ATS Serial Number:
#######
BY Back
Control Parameters
Controller Ser. #:
#######
BY Back
Control Parameters
Contactor Serial #:
#######
BY Back
Control Parameters
Site Designation:
NOT SET
BY Back
Control Parameters
Load Description:
NOT SET
BY Back
Control Parameters
Branch Description:
NOT SET
BY Back
Control Parameters
Location:
NOT SET
Note: Serial numbers are factory-set.
Use optional Monitor III software
to set other parameters.
