4.4 View Event History
The Event History screens show recent transfer switch
events. Examples of events recorded in the event
history are shown in Figure 4-2. Events are time- and
date-stamped. Check the event history for recent
transfer switch operation, faults, or changes to settings.
The event history is especially useful for transfer switch
troubleshooting.
BY "Main
View
Event History
B Back
Event Description
ON / OFF MM/DD/YY HH:MM
Additional Info
Press the right arrow
(
")buttontoview
events in the event
history log.
Press the down arrow
(B)buttontosteptothe
next event in the log.
Event Descriptions
End Time Delay Btn
Test Btn
Exercise Btn
Lamp Test
Service Req’d Reset
Maint DIP Switch
Pwd DIP Switch
Manual Option Switch
New Module
Contactor in Off
Contactor in Src N
Contactor in Src E
Low Battery
Exerciser Active
Fail to Acquire Pref
Fail to Acquire Stby
Fail to Sync
Fail to Transfer
I/O Module Lost Comm
Aux Switch Fault
Aux Switch Open
Rem End Time Delay
Forced Trans to Off
Peak Shave Mode
Inhibit Transfer
Remote Test
Low Battery Voltage
Remote Common Alarm
Bypass Contactor Dis
3 Src System Disable
Over Frequency
Under Frequency
Phase Loss
Phase Rotation Error
Over Voltage L1--L2
Over Voltage L2--L3
Over Voltage L3--L1
Under Voltage L1--L2
Under Voltage L2--L3
Under Voltage L3--L1
Voltage Imbalance
Save History To File
Auto Loaded Test End
Test Loaded Changed
Pref Source Changed
Reload Dflt Params
MODBUS Peak Shave
MODBUS Forced to OFF
MODBUS System Test
Battery Control Out
USB Connected
USB Disconnected
Minimum Values
Maximum Values
Breaker Trip
Figure 4-2 Examples of Event Descriptions
4.5 View Maintenance Records
BY "Main
View
Maintenance Records
BY Back
View Maintenance
Maintenance Item
#######
Press the right arrow
(
")buttontoview
maintenance items.
Press the down arrow
(B)buttontosteptothe
next maintenance item.
Maintenance Items
Minimum Values Reset Loss Pref Tran
Maximum Values Transfer Time N>E
Total Min not in Pref Transfer Time E>N
Reset Min Not Pref Dual Src Conn Time
Total Min in Standby S1 to Open Time
Reset Min in Standby S1 to Close Time
Total Min Operation S2 to Open Time
Reset Min Operation S2 to Close Time
Total Transfers System Start Date
Reset Transfers Last Maint Date
Total Fail Transfer Last Loss Date/Time
Reset Fail Transfer Last Loss Duration
Total Loss Pref Tran
