2.4.5 Ambient Conditions, Ventilation, and Mounting Position
Storage, hints (➜ # 47)
Transport, hints (➜ # 47)
Mains power supply
Aux. power supply
(with brake)
S701...S724:
1x110V-10% …1x230V+10%, 50/60 Hz
3x110V-10% …3x480V+10%, 50/60 Hz
S748...S772:
3x208V-10% ...3x 480V+10%, 50/60 Hz
24 V DC (-0% +15%), S701...724: 3A, S748...772: 5A
Check voltage drop!
Surrounding air tem-
perature in operation
0 to +40°C (32 to 104°F) at rated data
+40 to +55°C (113 to 131°F) with power derating 2.5% / K
Humidity in operation rel. humidity 85%, no condensation
Site altitude up to 1000m a.m.s.l. without restriction
1000 — 2500m a.m.s.l. with power derating 1.5%/100m
Pollution level Pollution level 2 to EN 60664-1
Vibrations Class 3M1 according to IEC 60721-3-3
Enclosure protection IP 20 according to EN60529
Mounting position generally vertical.
Ventilation built-on/built-in fan (optionally controlled, option F2)
The servo amplifier shuts down (error F01 and F13, motor
has no torque) in case of excessively high temperature in
the control cabinet.
Make sure that there is sufficient forced ventilation within
the switchgear cabinet.
2.4.6 Recommended Tightening Torques
S701...S724
Connector Recommended torque
X0, X8, X9 0.7 to 0.8 Nm (6.2 to 7.1 in lbf)
Ground bolt 3.5 Nm (31 in lbf)
S748...S772
Connector Recommended torque
X0/X8 with up to 25mm² wire 2.5 Nm (22 in lbf)
X0/X8 with 25 to 35mm² wire 4.5 Nm (40 in lbf)
X3A, X3B, X4 Cage clamps
X9A
Cage clamps. Mounting flange: 0.5 Nm (4.3 in lbf)
Ground bolt 3.5 Nm (31 in lbf)
54 Kollmorgen | wiki-kollmorgen.eu | February 2017
