2.4.9 Fusing
Internal Fusing
Circuit internal fuse
24V supply electronics 4 A
24V supply motor brake 4 A
Brake resistor electronic
External fusing
Fusible cutouts or similar S701/703 S706 S712 S724 S748 S772
AC supply F
N1/2/3
6 A 10 A 16 A 30 A 60 A 80 A
24V Electronics F
H1/2
max. 8 A
24V Motor brake F
H3/4
- max. 8 A
Brake resistor F
B1/2
40 A 40 A 40 A 50 A 100 A 100 A
2.4.10 Memory card
In the top of the servo amplifier there is a card reader for memory cards. The firmware and a
full set of parameters (with control buttons and setup software) can be stored on the memory
card and reloaded onto the servo amplifier. MMC and SD cards are supported.
This function means that a replacement device or identical shafts in standard production
machines can be set up very quickly and easily.
Uploads and Downloads from and to the memory card can be started with the keypad or with
the setup software using. Operating with ASCII commands is described in the Product-WIKI
on page " "Memory Card"".
Always switch off the servo amplifier before inserting or removing the memory card. If an
absolute encoder is used, homing must be carried out before the parameters are loaded into
a new device.
S700 Safety Guide | 2 English
Kollmorgen | wiki-kollmorgen.eu | February 2017 57
