2.7.2 Key operation / LED display
The two keys can be used to perform the following functions:
Key symbol Functions
press once : go up one menu item, increase number by one
press twice in rapid succession : increase number by ten
press once : go down one menu item, decrease number by one
press twice in rapid succession : decrease number by ten
press and hold right key, then press left key as well :
enter a number, return function name
2.7.2.1 Status display
2.7.2.2 Standard Menu
S700 Safety Guide | 2 English
Kollmorgen | wiki-kollmorgen.eu | February 2017 67
