2.4.8 Technical Data 230V ... 480 V
Rated data DIM S70102 S70302 S70602
S71202
S7120S
S72402
S7240S
S74802 S77202
Rated supply voltage (L1/L2/L3) V~ 3 x 208V
-10%
... 3 x 480V
+10%
, 50/60 Hz
Rated installed load for continuous oper-
ation @480V
kVA 1.1 2.2 4.5 9 18 35 50
Rated DC bus link voltage V= 450...900
Rated output current (rms value, ± 3%)
@ 3x208V Arms 2.5 5 6 12 24 48 72
@ 3x230V Arms 2 4 6 12 24 48 72
@ 3x400V or @ 3x480V Arms 1.5 3 6 12 24 48 72
Peak output curren (ca. 2s, ± 3%) Arms 4.5 9 18 24/30 48/72 96 140
Peak output curren (ca. 5s, ± 3%) Arms 3 6 12 24 48 96 140
Clock frequency of the output stage kHz 8 /16 with current derating
Quiescent dissipation, (disabled) W 20
25 25
Dissipation at rated current (incl. power
supply losses, without brake losses)
@480V
W 40 70 100 160 330 685 1135
Brake circuit
- max. continuous power @480V kW 0.3 1 1 1.5 4 8 8
- internal brake resistor Ohm 33 33 33 23 23 - -
- external brake resistor, optional Ohm 33 33 33 23 23 15 10
Overvoltage protection threshold V 455...905
Inputs/Outputs
Setpoint 1/2 V ±10
Common-mode voltage max. V ±10
Digital inputs - acc.to EN 61131-2 type 1, max. 30 VDC
Digital outputs, open emitter - max. 30 VDC, 100 mA
BTB/RTO output, relay contacts - max. 30 VDC, max. 42 VAC, 500 mA
Aux. power supply, electrically isolated
without brake
V 20 - 30 24 (-0% +15%)
A 1 2
Aux. power supply, electrically isolated
with brake
V 24 (-0% +15%)
A 3 5
Min./max. output current, brake A 0.15 / 2 0.15 / 3
Connections
Control signals — Mini-Combicon, 1.5 mm²
Power signals — Power Combicon 6 mm² Terminals
Feedback input — SubD (female)
PC interface, CAN, ROD/SSI — SubD (male)
Mechanical
Weight kg 4.4 5.5 13
Weight Coldplate (S7480C,S7480A) kg - - 10.4 -
Height without/with connectors mm 345 / 379 348 / 382 386 / 505
Width mm 70 100 190
Width without/with connectors mm 243 / 285 243 / 285 244 / 285
More technical data see Instructions Manual.
