Kollmorgen S700 Series

2.4.7 Technical Data 110 / 230 V
Rated data DIM S70162 S70362 S70662 S71262 S7126S S72462 S7246S
Rated supply voltage (L1/L2/L3) V~ 1 x 110V
-10%
... 3 x 230V
+10%
, 50/60 Hz
Rated installed load for continuous operation
@230V
kVA 1 2 2.3 4.5 4.5 9 9
Rated DC bus link voltage V= 135...450
Rated output current (rms value, ± 3%)
@ 1x110V Arms 1,5 3 6 7 7 10 10
@ 1x230V Arms 1,5 3 6 8 8 11 11
@ 3x110V Arms 2,5 5 6 12 12 24 24
@ 3x230V Arms 2,5 5 6 12 12 24 24
Peak output current (rms value, ± 3%)
@ 1x110, duration 2s / 5s Arms 3/3 3/3 6/6 7/7 7/7 10/10 10/10
@ 1x230V, duration 2s / 5s Arms 4.5/3 9/6 12/12 12/12 12/12 13/13 13/13
@ 3x110V, duration 2s / 5s Arms 4.5/3 9/6 18/12 24/24 30/24 48/48 72/48
@ 3x230V, duration 2s / 5s Arms 4.5/3 9/6 18/12 24/24 30/24 48/48 72/48
Clock frequency of the output stage kHz 8 /16 with current derating
Quiescent dissipation (disabled) W 4
6
Dissipation at rated current (incl. power
supply losses, without brake losses) @230V
W 30 45 60 90 90 175 175
Brake circuit
- max. continuous power @230V kW 0.3 1 1 1.5 1.5 4 4
- internal brake resistor Ohm 33 33 33 33 33 23 23
- external brake resistor, optional Ohm 33 33 33 33 33 23 23
Overvoltage protection threshold V 140...455
Inputs/Outputs
Setpoint 1/2 V ±10
Common-mode voltage max. V ±10
Digital inputs - acc.to. EN 61131-2 type 1, max. 30 VDC
Digital outputs, open emitter - max. 30 VDC, 100 mA
BTB/RTO output, relay contacts - max. 30 VDC, max. 42 VAC, 500 mA
Aux. power supply, electrically isolated
without brake
V 20 - 30
A 1
Aux. power supply, electrically isolated with
brake
V 24 (-0% +15%)
A 3
Min./max. output current, brake A 0.15 / 2
Connections
Control signals — Mini-Combicon , 1.5 mm²
Power signals — Power Combicon 6 mm²
Feedback input — SubD (female)
PC interface, CAN, ROD/SSI — SubD (male)
Mechanical
Weight kg 4.4 5.5
Height without/with connectors mm 345 / 379 348 / 382
Width mm 70 100
Width without/with connectors mm 243 / 285 243 / 285
More technical data see Instructions Manual.
