Productdescription

•Antennapigtailcable

•Interconnectioncable

•Mainscable

•Antennamountingrod

TheDPS232unitincludesacombinedGPS/GLONASSL1/L2andSBASreceiver.The

receiverhas14L1and14L2GPSchannels,12L1and12L2GLONASSchannelsand2

SBASchannels.TheSBASsignalshavethesamefrequencyastheGPSL1signals,so

onlyoneGPS/GLONASSantennaisneeded.

Figure1TypicalDPS232conguration

Inadditiontotheabovedeliveredparts,thefollowingisneeded:

•CoaxcableforGNSSantenna

•CoaxcableforIALAbeaconantenna

•Coaxconnectors

•DGNSScorrectionsononeormoreseriallinesforimprovedpositionaccuracy

(recommended)

•Monitor

•AdditionalcablesforinputofDGNSScorrections

•AdditionalcablesforoutputtoexternalDGNSSequipment

GeneralarrangementdrawingsoftheshipshouldbeacquiredtosimplifyGNSSantenna

mountingandtoestimatesufcientlengthsofcable.
