Technicalspecications

3.12InterfacesProcessingUnit

3.12.1InterfacesProcessingUnitfront

Thepowerswitch,LAN1andUSB1arelocatedbehindthelid

totheleftonthefrontpanel.Pushlidonleftsidetoopenorip

openusingslitonrightside.

3.12.2InterfacesProcessingUnitrear

TherearpaneloftheProcessingUnitcontainscommunicationinterfaceportsfor

interfacingtoexternalequipment.

Figure2RearpanelofProcessingUnitwithconnectorboard

Table1ConnectorsattherearoftheProcessingUnit

Connector

Type

Connectedto

GNSS1

Nconnector50Ohm

female

GNSSantenna

GNSS2

Nconnector50Ohm

female

Notusedinthissystem

IALA

Nconnector50Ohm

female

IALAbeaconantenna

LAN2

RJ-45–10/100/1000

Mbit/s

Usercongurable

USB2USB

Usercongurable

USB3USB

Usercongurable

G210-14/3.0
