Kongsberg DPS 232 - Vessel Shape from File

KongsbergDPS232
Originlocationindrawing
Allpointlocationsinthecongurationrefertotheorigin.Thelocationoftheoriginis
denedusingdistancefromstern,centerlineandkeel(oftenreferredtoastheCRP—
coordinatereferencepoint—insurveyreports).
Fromstern
ThedistancefromtheaftpointoftheshiptooriginalongtheXaxis.
FromCL
Thedistancefromthevessel’scentreline,positivetowardsstarboard.
Fromkeel
Thedistancefromthekeel,positivedownwards.
Figure16DifferentdimensionsandlocationofOrigin
Relatedtopics
•Vesselshapefromleonpage52.
5.4.2Vesselshapefromle
Thepre-denedscalablevesselshapesrepresenttheactualvesseloutlineonlyinrare
cases.Inordertoconguretheaccuratelocationofvarioussensors,equipmentand
monitoringpoints,itisrecommendedtoloadaseparatevesselmodelfromle.
SelecttheUsevesseldrawingcheckbox,thenclicktheBrowse...buttontobrowsefor
animagele.Threeletypesareavailable:Vesselmodels(*.svm),Vesselvectorimages
(*.svi)andOldvesselimages(*.txt).
