Kongsberg DPS 232 - GNSS Antenna Installation

Mechanicaldrawings
8.5GNSSantennainstallation
ExcerptfromGPS-702-GG,GPS-701-GGandGPS702-GG-NUserGuide,
OM-20000095,rev.1B,August7,2009,NovAtelInc.
Howtoinstalltheantenna
Afterasitehasbeenselected,installtheantennaasfollows.
1Verifythatthethreadonthemountdoesnotextendmorethan7/8"(22mm)to
ensuretheplasticinsidetheantennareceptacleisnotdamagedwhenthemountis
inserted.Ifitextendsfurtherthan7/8"(22mm),addtwojamnutstoshortenthe
exposedthread,ensuringthenutsarewell-tightened.
2
Alignthemountthreadwiththemetaladapter
onthebottomoftheantennaandrotatethe
antennaclockwiseuntilitissecurelyscrewed
tothemount.Usingawrench,tightenthe
adaptertothemount.
3Removethedustcapfromtheantenna's
N-Typeconnector.
4AttachthemaleN-Typeconnectorofthe
coaxialcabletotheantenna'sN-Type.
Note
Themetaladapteronthebottomoftheantennaisxedinplace.Donotattempt
toremoveit.
5Attachtheendofthecoaxialcabletotheantennainputportofthereceivingdevice.
AllNovAtelGNSSreceiversprovidethenecessarypowerthroughtheirantenna
RFconnectors.
G210-14/3.0
91
