Kongsberg DPS 232 - IALA Beacon Antenna and Cable Installation

KongsbergDPS232
4Dependentonthecableinstallation,securethecabletothemasteveryonetothree
metreswithclampsorbands(nonmetal).
Note
ThecablerunningfromtheGNSSantennatotheProcessingUnitshouldbeas
straightaspossible.Donotcrushorcrimpthecablewithtie-downs,asthiswill
affecttheelectricalpropertiesofthecable.
5Checktheantennacableforshort-circuiting.Routetheconnectorattheotherend
oftheantennacabletothemainunit.
6ConnectthecabletotheProcessingUnit.Ashortinterconnectioncableisdelivered
inordertogetsecurecablerunsintothecabinet.
Relatedtopics
•SeeGNSSantennainstallationonpage91formoredetails.
4.5.2IALAbeaconantennaandcableinstallation
Theconstructionofthemountenablesroutingofthecableeitheralongtheinsideorthe
outsideofthemasttube.AnRG-214cableisusedfordistancesshorterthan50metres,
whilean½"superexcableisusedfordistanceslongerthan50metres.
Caution
IftheantennacableisattachedtotheProcessingUnit,donotattachthe
antennacabletotheantennawhentheunitisrunning.Iftheantennacable
isshort-circuitedwithPOWERON,theIALAbeaconreceiverwillbedamaged.
HowtoinstalltheIALAbeaconantenna
1AttachtheantennatoamasttubeorpolebyusingtheprovidedU-bolts.
2Attachtheantennacabletotheantenna.
3Wrapoutdoorcableconnectionswithwaterproofself-vulcanisingtape.Analternate
wayofwaterproongistouseheatshrinkhosewithglue.Thehoseshouldcover
thewholeconnectorandpartofthecable.
4Makesurethegroundstrapattheantennabaseisconnectedtoasuitableplace
ensuringgoodgrounding.Wheninstalled,theterminalsofthegroundstrap
shouldbesealedfrommoisturetopreventcorrosion.Paintorsiliconesealantis
recommendedforthis.
5Securethecabletothemasteveryonetothreemetreswithclampsorbands.
6Routetheconnectorattheotherendoftheantennacabletothemainunit.Connect
thecabletotheProcessingUnit.AshortRG-214cableisoftenneededinorderto
securecablerunsintothecabinet.Thiscableisincludedinthepackage.
Relatedtopics
•SeeOptionalIALAbeaconantennaonpage109formoredetails.
44
G210-14/3.0
