Installation

4Installation

ThischaptercoversinstallationoftheProcessingUnitandtheGNSSandIALAbeacon

antennas.AseparateInstallationmanualcoversSeastardemodulatorinstallationand

connectiontotheInmarsatterminalonboardthevesselforreceptionofDGNSS

correctionsignals.

Note

TheProcessingUnithasaplasticlmontoptoprotectfromtransportscratches.This

lmmustberemovedbeforeoperationastheplasticlmwillreducetheheattransfer

fromtheunitandthuscausetemperatureincreaseinsidetheunit.

Theinstallationincludes:

•Locationofthesystemparts(theProcessingUnit,GNSSantennaandIALAbeacon

antenna)

•Installationofthecoaxconnectors

•InstallationoftheGNSSantenna(s)andcable(s)

•InstallationoftheIALAbeaconantennaandcable

•ConnectionofcablesbetweenDPSsystemandexternalequipment

•Systemconguration

4.1Logistics

Safety

Generalsafetyguidelinesshouldbefollowedwhenworkinginmastandondeck.

Personnelqualications

Trainedelectricalworkers.

Specialtoolsrequired

None.
