Technicalspecications

Table4Pinlayoutofserialinput/outputlines(cont'd.)

Pinno.Signal

RS-422RS-232

3GNDGND

4TX_ARTS

5TX_BTX

3.12.5.2Alarmsignal

TheProcessingUnithasabuilt-inalarmfunctionalityandcanbeconnectedtoan

externalalarm.Analarmwillopenthealarmrelay,whichcanbeusedtotriggeran

externalalarm.TheexternalalarmcanbeconnectedtotheAlarm3pinterminal.

Table5PinlayoutofAlarmport

Pinno.Signal

Alarm_NO

Alarm_Com

3NC

ThediagramshowshowanexternalalarmcanbeconnectedtotheProcessingUnit

ALARMterminal.

Figure5Externalalarmconnectiondiagram

G210-14/3.0
