Konica Minolta bizhub C203 Service Manual

Field Service Ver. 1.0 Jul. 2007 5. Firmware upgrade
57
bizhub C353/C253/C203Maintenance
5.3.6 Screen
A. Main window
• The main window will be displayed after activating the software.
• Main window consists of 2 patterns: Basic mode, Advanced mode
[1] About • To display the outline of the tool.
[2] Copyright Info • To display the license agreement and version information of the
tool.
[3] Settings • To display the dialog to enable the advanced functions.
• Select the check box of [Enabled Advanced Features] to enable
advanced functions at main window.
See P.58
[4] What would you like to
do?
• To select the function to be used.
• Displayed screen is different between Basic mode and
Advanced mode.
See P.59
[5] Select the location of the
Firmware to write to the
card:
• To select the compact flash drive to which the data to write.
[6] Select the drive letter that
corresponds to the card
you wish to write to:
• To select the location where the firmware is stored in PC.
9J06F2E704DA
When the advanced mode is selected
[1]
[2]
[3]
[5]
[6]
[4]

Konica Minolta bizhub C203 Specifications

General

Print Resolution	600 x 600 dpi
Print Technology	Laser
Memory (Standard)	1 GB
Paper Output	250 sheets
Scan Resolution	600 x 600 dpi
Print Speed	20 ppm (black/color)
Copy Speed	20 cpm (black/color)
Standard Paper Size	A4, A5, B5
Connectivity	Ethernet (10/100Base-TX), USB 2.0
Weight	85 kg
Functions	Print, Copy, Scan
First Print Time (Color)	15 seconds
Duplex Printing	Yes
Scan to	Email, FTP, USB
Paper Capacity	Standard: 1, 150 sheets
Type	Color Multifunction Printer
