Konica Minolta bizhub C203 Service Manual

9. Malfunction code Field Service Ver. 1.0 Jul. 2007
82
FS-519/PK-515/OT-602
Troubleshooting
9.2.7 C11A3: Shutter drive failure
9.2.8 C11B0: Staple unit CD drive failure
Relevant electrical parts
Shutter motor (M8)
Shutter home position sensor (PS14)
Relay board/1 (REYB/1)
FS control board (FSCB)
Step Action
WIRING DIAGRAM
Control signal
Location
(Electrical
component)
1
Check the M8 connector for proper con-
nection and correct as necessary.
——
2
Check M8 for proper drive coupling and
correct as necessary.
——
3 M8 operation check FSCB PJ6FSCB-7 to 8 FS-519 J-5
4 PS14 I/O check, sensor check FSCB PJ18FSCB-5 (ON) FS-519 J-5
5 Change REYB/1 — —
6 Change FSCB — —
Relevant electrical parts
Stapling unit moving motor (M7)
Staple home position sensor (PS9)
FS control board (FSCB)
Step Action
WIRING DIAGRAM
Control signal
Location
(Electrical
component)
1
Check for interference with the shutter
and exit roller, and correct as necessary.
——
2
Check the M7 connector for proper con-
nection and correct as necessary.
——
3
Check M7 for proper drive coupling and
correct as necessary.
——
4 M7 operation check FSCB PJ10FSCB-1 to 4 FS-519 C-3 to 4
5 PS9 I/O check, sensor check FSCB PJ13FSCB-5 (ON) FS-519 C-4 to 5
6 Change FSCB — —

Konica Minolta bizhub C203 Specifications

General

Print Resolution	600 x 600 dpi
Print Technology	Laser
Memory (Standard)	1 GB
Paper Output	250 sheets
Scan Resolution	600 x 600 dpi
Print Speed	20 ppm (black/color)
Copy Speed	20 cpm (black/color)
Standard Paper Size	A4, A5, B5
Connectivity	Ethernet (10/100Base-TX), USB 2.0
Weight	85 kg
Functions	Print, Copy, Scan
First Print Time (Color)	15 seconds
Duplex Printing	Yes
Scan to	Email, FTP, USB
Paper Capacity	Standard: 1, 150 sheets
Type	Color Multifunction Printer
