Konica Minolta bizhub C203 Service Manual

Field Service Ver. 1.0 Jul. 2007 6. Other
93
bizhub C353/C253/C203Maintenance
4. Remove two screws [1], and discon-
nect the connector [2].
5. Remove six screws [1], and remove
the control panel assy [2].
6.3.21 Exit tray
1. Open the front door.
2. Remove the left cover.
See P.85
3. Remove three screws [1], and
remove the exit tray [2].
A02EF2C066DA
[1]
[2]
A02EF2C067DA
[1]
[1]
[2]
[1]
A02EF2C068DA
[1]
[2]

Konica Minolta bizhub C203 Specifications

General

Print Resolution	600 x 600 dpi
Print Technology	Laser
Memory (Standard)	1 GB
Paper Output	250 sheets
Scan Resolution	600 x 600 dpi
Print Speed	20 ppm (black/color)
Copy Speed	20 cpm (black/color)
Standard Paper Size	A4, A5, B5
Connectivity	Ethernet (10/100Base-TX), USB 2.0
Weight	85 kg
Functions	Print, Copy, Scan
First Print Time (Color)	15 seconds
Duplex Printing	Yes
Scan to	Email, FTP, USB
Paper Capacity	Standard: 1, 150 sheets
Type	Color Multifunction Printer
