DF-606
1. PRODUCT SPECIFICATIONS
1
Field Service Ver1.0 Jun.2005
OUTLINE
1. PRODUCT SPECIFICATIONS
A. Type
B. Functions
C. Original
Name Double sided original auto feeder
Type Sheet-through type original auto feeder
Original size Metric: A3, B4, A4, A4R, B5, B5R, A5, A5R, B6R, 11 x 17, 8.5 x 11,
8.5 x 13
Inch: 11 x 17, 8.5 x 14, 8.5 x 11, 8.5 x 11R, 5.5 x 8.5, 5.5 x 8.5R, A3,
B4, A4, B5, B5R, A5, A5R, B6R
Taiwan spec: A3, A4, A4R, A5, A5R, 8K, 16K, 16KR
Maximum original size: 297 x 431.8 mm
Minimum original size: 128 x 139.7 mm
Original stacking capacity 100 sheets, max. (80g/m
2
or 20 lbs)
Original read speed (A4
size)
Single sided copy mode: 92 sheets/min.
Double sided copy mode: 65 sheets/min.
Original feed layout Set with the front side up, at center as standard
Original image read position Dedicated slit glass section
Resolution 600 dpi
Type of paper High-quality paper of 50 to 130 g/m
2
In the case of the single sided original mode, however, high-quality paper of
131 to 200 g/m
2
is also available.
Amount of curling Up to 10 mm with 5 originals overlapped one another
a Amount of curling: up to 10 mm
[1] Original
Originals other than those
that paper feed and
throughput can be guaran-
teed
With the following originals, no severe problems are found such as frequent jams
and major damage to the originals, although it is not possible to obtain a numeric
value indicating reliability that can be specified in product guarantee terms:
Recycled paper, straw paper, heat sensitive paper, originals fed in the mixing
of perforated original mode, high-quality paper of 35 to 50 g/m
2
, irregular-
sized originals (such as CF originals), coated paper, originals with a rough
surface (such as letterhead), folded originals (Z-folded or folded in two)
15sat1c001na
[1]
a
To Next Page
