2. PERIODIC CHECK
26
Field Service Ver2.0 Aug.2005
FS-509/604
22. Remove 2 screws [1], and then remove the
mounting plate [3] from the stapler /Rr [2].
23. Reinstall the above parts following the removal
steps in reverse.
[2][3] [1]
15sjf2c026na
