34
2.1 Overview of this device
This section describes the functions of this device as well as a system conguration and connection examples using
this device.
2.1.1 Functions
The AeroDR SYSTEM consists of DR Detector (AeroDR 1417HQ, AeroDR 1417S, AeroDR 1717HQ and AeroDR
1012HQ), AeroDR Interface Unit, AeroDR Interface Unit2, AeroDR Generator Interface Unit, AeroDR Battery Char-
ger, AeroDR Battery Charger2, AeroDR Access Point, etc. With the DR Detector, diagnostic X-ray digital image data
is generated by the irradiation signal and exposure from an X-ray device, and sent to the image processing control-
ler.
Furthermore, the DR Detector can be connected with (or inserted in) the AeroDR Interface Unit, AeroDR Interface
Unit2, AeroDR Battery Charger and AeroDR Battery Charger2 or removed from them.
The AeroDR SYSTEM 2 consists of the DR Detector (AeroDR 2 1417HQ and AeroDR 2 1417S), AeroDR Interface
Unit, AeroDR Interface Unit2, AeroDR Generator Interface Unit, AeroDR Generator Interface Unit2, AeroDR Battery
Charger, AeroDR Battery Charger2, etc. With the DR Detector, diagnostic X-ray digital image data is generated by
the irradiation signal or exposure from an X-ray device and sent to the image processing controller.
Furthermore, the DR Detector can be connected with (or inserted in) or removed from the AeroDR Interface Unit,
AeroDR Interface Unit2, AeroDR Battery Charger and AeroDR Battery Charger2.
The SKR 3000 consists of the DR Detector (AeroDR 3 1417HD, AeroDR 3 1717HD and AeroDR 3 1012HQ), AeroDR
Interface Unit, AeroDR Interface Unit2, Detector Interface Unit, Detector Interface Unit 2, Power Supply Unit, AeroDR
Generator Interface Unit, AeroDR Generator Interface Unit2, Generator Interface Unit 3, AeroDR Battery Charger2,
etc. The DR Detector uses the exposure signal or exposure from the X-ray device to generate X-ray digital image
data for diagnosis, including serial exposure images, and send to the image processing controller.
Furthermore, the DR Detector can be connected with (or inserted in) or removed from the AeroDR Interface Unit,
AeroDR Interface Unit2, Detector Interface Unit, Detector Interface Unit 2 and AeroDR Battery Charger2.
