KT690 Family
KTD-00738-C Public User Manual Date: 2008-09-16 Page 12 of 91
I/O Control
Winbond W83627DHG LPC Bus I/O Controller
Peripheral
interfaces
• Six USB 2.0 ports on I/O area
• Four USB 2.0 ports on internal pinrows
• Two Serial ports (RS232)
• One Parallel port, SPP/EPP/ECP
• One Floppy port
• Four Serial ATA-300 IDE AHCI interfaces
• One PATA 66/100/133 interface with support for 2 devices
• CF (Compact Flash) interface (KT690/mITX only) supporting CF type I and II.
(UDMA2 max.). Note that only one PATA device is supported when CF is used and
only by use of 40-wire cable (not 80-wire cable). Optionally use SATA devices.
• Two IEEE 1394-1995/ 1394a-2000 OHCI Firewire ports supporting speeds of 100
Mbits/s, 200 Mbits/s, and 400 Mbits/s (KT690-FW/mITX only)
• PS/2 keyboard and mouse ports
LAN
Support
• 2x 10/100/1000Mbits/s LAN using Realtek RTL8111B controllers
• RPL/PXE netboot supported. Wake On LAN (WOL) supported.
BIOS
• Kontron Technology / AMI BIOS (core version 8.00)
• Support for Advanced Configuration and Power Interface (ACPI 1.0b), Plug and Play
o Suspend To Ram (S3)
o Suspend To Disk (S4)
• Support for Cool’n’Quiet™
• Secure CMOS/ OEM Setup Defaults
• “Always On” BIOS power setting
• Desktop Management Interface (DMI)
• Support for addition of System Locked Preinstallation (SLP) key in BIOS
• Setup for Forced Boot device
• RAID Support (RAID modes 0, 1, and 10) (for Linux O/S limitations may apply)
• TPM onboard
Expansion
Capabilities
• PCI Bus routed to PCI slot(s) (PCI Local Bus Specification Revision 2.3)
o KT690/mITX: 1 slot
PCI 2.3, 32 bits, 33 MHz, 5V compliant
• PCI-Express bus routed to PCI Express slot(s) (PCI Express 1.1a)
o KT690/mITX: 1 slot
PCI-Express x16 with PCI-Express x8 support
• Mini PCI-Express routed to mini PCI-Express connector
Support for Mini PCI-Express modules with no components on backside.
• SMBus routed to FEATURE, PCI slot, PCI Express and mini-PCI Express connectors
• LPC Bus routed to TPM connector
• DDC Bus routed to LVDS and CRT connector
• 8 x GPIOs (General Purpose I/Os) routed to FEATURE connector
Hardware
Monitor
Subsystem
• Smart Fan control system, support Thermal® and Speed® cruise for three onboard
Fan control connectors: FAN_CPU, FAN_SYS and FEATURE
• Three thermal inputs: CPU die temperature, System temperature and External
temperature input routed to FEATURE connector. (Precision +/- 3ºC)
• Voltage monitoring
• Intrusion detect input
• SMI violations (BIOS) on HW monitor not supported. Supported by API.
Operating
Systems
Support
• WinXP
• Windows Vista
• Windows 2003
• WinXP Embedded
• Linux: Feodora Core 8
(continues)
To Next Page
