8.5.1 Boot – Boot Settings Configuration
BIOS SETUP UTILITY
Boot
Boot Settings
Quick Boot [Enabled]
Quiet Boot [Disabled]
AddOn ROM Display Mode [Force BIOS]
Bootup Num-Lock [On]
PS/2 Mouse Support [Auto]
Wait for ‘F1’ If Error [Enabled]
Hit ‘DEL’ Message Display [Enabled]
Interrupt 19 Capture [Disabled]
PC Speaker/Beep [Enabled]
Force boot Device [Disabled]
Configure Settings
during System Boot.
<- Select Screen
|| Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature Options Description
Quick Boot
Enabled
Disabled
Allows BIOS to skip certain test while booting in
order to decrease boot time.
Quiet Boot
Disabled
Enabled
Disabled: Displays normal POST messages.
Enabled: Displays OEM Logo (no POST messages).
AddOn ROM Display Mode
Force BIOS
Keep current
Set display mode for Option ROM.
Bootup Num-Lock Off
On
Select Power-on state for numlock
PS/2 Mouse Support Disabled
Enabled
Auto
Select support for PS/2 Mouse.
Wait for ‘F1’ If Error
(see note)
Disabled
Enabled
Wait for F1 key to be pressed if error occurs.
Hit ‘DEL’ Message Display Disabled
Enabled
Displays “Press DEL to run Setup” in POST.
Interrupt 19 Capture
Disabled
Enabled
Enabled: Allows option ROMs to trap interrupt 19
PC Speaker/Beep Disabled
Enabled
Control the default beeps during boot of the system.
This setting will aldo control the beep during
enumeration and (un)plug of USB.
Force boot Device
Disabled
Primary IDE Master
Primary IDE Slave
Secondary IDE Master
Secondary IDE Slave
Third IDE Master
Third IDE Slave
Network
Does override current boot setting. Device must be
in the boot priority menu though. If the device fails to
boot, the system will NOT try other devices.
Note: List of errors:
<INS> Pressed Primary Master Hard Disk Error PCI I/O conflict
Timer Error S.M.A.R.T HDD Error PCI ROM conflict
Interrupt Controller-1 error Cache Memory Error PCI IRQ conflict
Keyboard/Interface Error DMA Controller Error PCI IRQ routing table error
Halt on Invalid Time/Date Resource Conflict
NVRAM Bad Static Resource Conflict
