Kontron KT690/mITX - IDE Hard Disk Connector (PATA)

KT690 Family
KTD-00738-C Public User Manual Date: 2008-09-16 Page 39 of 91
4.6.1 IDE Hard Disk Connector (PATA)
This connector can be used for connection of two primary IDE drives.
Note
Pull
U/D
Ioh/Iol Type Signal PIN Signal Type Ioh/Iol
Pull
U/D
Note
- TBD O RESET_P# 1 2 GND PWR - -
- TBD IO DA7 3 4 DA8 IO TBD -
- TBD IO DA6 5 6 DA9 IO TBD -
- TBD IO DA5 7 8 DA10 IO TBD -
- TBD IO DA4 9 10 DA11 IO TBD -
- TBD IO DA3 11 12 DA12 IO TBD -
- TBD IO DA2 13 14 DA13 IO TBD -
- TBD IO DA1 15 16 DA14 IO TBD -
- TBD IO DA0 17 18 DA15 IO TBD -
- - PWR GND 19 20 KEY - - -
- - I DDRQA 21 22 GND PWR - -
- TBD O IOWA# 23 24 GND PWR - -
- TBD O IORA# 25 26 GND PWR - -
4K7 - I IORDYA 27 28 GND PWR - -
- - O DDACKA# 29 30 GND PWR - -
10K - I HDIRQA 31 32 NC - - -
- TBD O DAA1 33 34 CBLIDA# I -
- TBD O DAA0 35 36 DAA2 O TBD -
- TBD O HDCSA0# 37 38 HDCSA1# O TBD -
- - I HDACTA# 39 40 GND PWR - -
