KT690 Family
KTD-00738-C Public User Manual Date: 2008-09-16 Page 70 of 91
8.3.3 Advanced settings – LAN Configuration
BIOS SETUP UTILITY
Advanced
LAN Configuration
ETH1 Configuration (Left) [Enabled]
MAC Address : 00E0F4000001
ETH2 Configuration (Right) [Enabled]
MAC Address : 00E0F4000002
Control of Ethernet
Devices and PXE boot
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature Options Description
ETH1 Configuration Disabled
Enabled
With RPL/PXE boot
Select if you want to enable the LAN adapter, or if
you want to activate the RPL/PXE boot rom
ETH2 Configuration Disabled
Enabled
With RPL/PXE boot
Select if you want to enable the LAN adapter, or if
you want to activate the RPL/PXE boot rom
8.3.4 Advanced settings – Floppy Configuration
BIOS SETUP UTILITY
Advanced
Floppy Configuration
Floppy A [Disabled]
Select the type of
floppy drive
connected to the
system.
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature Options Description
Floppy A
Disabled
Enabled
Select the type of floppy drive connected to the
system.
